How to playback and download recordings on the Camius VMS (IP Camera, DVR, NVR software)

To play your DVR or NVR footage remotely on the VMS software, navigate to the Home tab >> Remote Playback (Picture 1).

VMS remote playback
Picture 1

See below the description of each function in the following picture and a table:

VMS remote recording playbcak table icons
VMS remote playback icons 1 1

Then expand ‘root’ on the left sidebar (Picture 2), then click the checkboxes for cameras that captured the event (Pictures 3 and 4)

VMS root
Picture 2
VMS root IPVAULT2256PR SELECT CAMERAS TO CHECK scaled
Picture 3
VMS root IPVAULT2256PR SELECT CAMERAS TO CHECK
Picture 4

Next, on Calendar, you can choose which stream recording event type and click on the Calendar icon and the day of the event. Only days with recorded footage will have a red flag (Pictures 5 and 6).

VMS root CALENDAR point
Picture 5
VMS root CALENDAR CLICK ON DATE21 scaled
Picture 6

Cameras will playback individually once you click the Play button and click on each camera’s timeline on the desired hour (Picture 7).

VMS root CALENDAR CLICK ON DATE PLAY FOOTAGE scaled
Picture 7

To download recordings follow the below steps:

Step 1: Select a video window that has enabled recording, and click  the download button in the playback control area. A dialog box is displayed, as shown in the following picture:

vms pro dowload icon
vms pro dowload record file

Step 2: Select the recording you want to download and specify the storage path.

Step 3: Click download.
