Camius 4K NVR bundled with 4K ethernet powered security cameras for Home and Business Security
This Camius bundle provides you with a dependable and high-quality solution with surveillance cameras for home security and small retail commercial locations. It consists of a Camius 8 channel 4K NVR with a preinstalled hard disk and 8 Camius 4K PoE dome cameras. You can enjoy clear and detailed video recording and monitoring in any lighting condition with these devices.
Powerful Network Video Recorder
The Camius 4K NVR is a versatile and powerful network video recorder supporting up to 8 IP cameras. Its integrated 8-port PoE switch powers and connects cameras seamlessly. The NVR includes a pre-installed 4TB hard drive for continuous, motion-based, or scheduled recording. With H.265+ video compression, bandwidth and storage use can be reduced by up to 50%. You can also fine-tune recording settings, including resolution, frame rate, bit rate, motion, sound, AI detection, and schedule.
Key Features of Camius 4K Wired Ethernet Camera:
- 4K Ultra HD Resolution: Capture every detail with 8MP clarity.
- Wide-Angle View: 110° horizontal view covers more area with fewer cameras.
- AI-Powered Security: Advanced detection features available when paired with Camius NVRs.
- Rugged Design: IP66-rated, suitable for both indoor and outdoor use.
PoE Simplifies - Installation: Single cable for power, audio, and video.
4K PoE Security Camera with Audio and Smart Detection
The Camius 4K Dome Camera offers advanced surveillance capabilities with its smart motion detection, vehicle and pedestrian recognition, and integrated sound and AI detection features. This cutting-edge technology ensures precise monitoring by distinguishing between different types of movement, such as vehicles and pedestrians, and identifying unusual sounds or events. With AI-driven analytics, the camera enhances security by reducing false alarms and delivering accurate alerts, making it an ideal choice for comprehensive and reliable surveillance.
4K NVR Camera System with Remote Access
You can monitor your home or business remotely using the free Camius app and NVR desktop software. The Camius NVR camera system is web browser-compatible. You can access the security system remotely using a peer-to-peer connection or setup an easy-to-remember hostname using the DDNS server. You can view live video, playback recorded footage, receive alerts, take snapshots, record videos, etc. This Camius bundle is a complete and cost-effective solution for businesses. It offers you peace of mind and protection for your business and commercial premises.
Included:
- 8 channel NVR with pre installed 4TB hard disk (IPVault1128PR 4TB HDD)
- 8 x 4K PoE dome cameras (IRIS8R)
- 8 x Cat5e 60ft cable
Recommended Resources:
– NVR Installation Guide
– IP Camera Installation Guide
Camius 8 Channel NVR Technical Specifications
- Model: IPVAULT1128PR
- Recording Bandwidth: 128 Mbps
- Camera Support: View and record up to 8 HD IP cameras
- Network Interface: 8 LAN ports (Power-over-Ethernet) for seamless installation of Camius IP PoE cameras
- Camera Compatibility: Supports 4K (8 Megapixels) IP cameras
- Video Quality: Live view and playback resolutions up to 4K at 45fps, 4MP at 90fps, 2MP at 180fps
- Bitrate: Supports bitrate ranging from 64K to 16M
- Recording Modes: Dual or mainstream recording options, with features like Pre-recording (5sec), Schedule Recording, Capture Schedule, and Event triggered recording
- Encoding:
- Mainstream: 4K (3840 x 2160), 5.3MP (3072 x 1728), 2K (2880 x 1620), 2592 x 1944, 2592 x 1520, 2304 x 1296, 1080P (1920 x 1080), 1280 x 960, 1280 x 720 @ 30fps
- Substream: 1280 x 720, 640 x 480, 320 x 240, 1920 x 1080 @ 30fps
- Mobilestream: 320 x 240, 640 x 480 @ 30fps
- Audio Control: Manage Camius IP camera audio settings and volume
- Storage Capacity: Accommodates 1 internal SATA Hard drive up to 10TB; supports Net HDD (NAS) expansion
- Video Outputs: HDMI output supporting up to 4K resolution, VGA – 1080P video resolution
- Management Features: Includes user and logs management
- Alarm: Notifications via email and smartphone push notifications; supports FTP and Cloud (Dropbox/Google Drive) uploads, show a message NVR buzzer sound
- Deterrence: Available for supported Camius IP cameras, featuring lights and siren capabilities for enhanced security measures
- Playback Capabilities: Supports Date & Time search, as well as various search types including Normal, IO, PIR, Sound, Manual, Motion, and Intelligent; Smart Search functionality for efficient video retrieval
- Playback Modes: Fast forward / backward options (2x, 4x, 8x, 16x), as well as slow forward playback (1/2x, 1/4x, 1/8x, 1/16x) for detailed video analysis
- Intelligent Analytics: Supports advanced analytics for supported Camius IP cameras, including Face detection, Human & Vehicle Detection, Perimeter Intrusion, Line Crossing, Stationary Object Detection, Cross Counting, Sound Detection & more (some new features are in beta)
- User Interface: Front and rear USB ports for mouse control, backup, and firmware upgrades
- Language Options: Multiple menu languages available (English, Spanish, Portuguese, French, etc)
- Compatibility: Works with PC, Mac, and web browsers; Camius View app available for iOS and Android
- Network Protocols: Supports DHCP, PPPOE, DDNS, HTTPS, RTSP, UPNP; optimized for seamless network integration; P2P (peer to peer) for remote access
- WAN Connectivity: 1 RJ45 100/1000 Base-T1 port for wide area network (WAN) connection, ensuring high-speed data transfer capabilities over Ethernet
- Cloud Integration: Compatible with Dropbox and Google Drive for secure cloud storage
- Maintenance: Firmware upgrades and parameter management; reset button to load default settings, resetting the password
- Environmental Conditions: Operating temperature range of 32°F to 104°F (0°C to +40°C); designed for reliable performance in various environments
- Power Supply: DC48V/1.5A; PoE (IEEE 802.3af) with 48V power supply for 8 built-in PoE ports, ensuring stable power delivery
- Dimensions: Compact design measuring 12 x 9 x 2 inches (300 x 227 x 53mm) for easy integration into diverse setups
- Package Contents: Includes IPVAULT1128PR NVR, power supply, power cord, HDMI cable, network cable, USB mouse, screws for HDD installation, and NVR Installation Guide
Note: Design and specifications are subject to change without notice as we continually enhance our products. For the latest information, please visit Camius Website.
Camius 4K PoE Dome Camera Technical Specifications
- Model: IRIS8R
- Type: 4K PoE Dome IP Camera
Key Specifications:
- Resolution:
- Main Stream: 8MP (3840 x 2160) @ 20fps
- Sub Stream: 1280 x 720 @ 20fps
- Mobile Stream: 640 x 480 @ 20fps
- Image Sensor: 1/2.8” Progressive CMOS
- Lens:
- Focal Length: 2.8mm
- Field of View: Horizontal 110°, Vertical 58°, Diagonal 132°
- Low Light Performance:
- Color: 0.1 Lux @ F1.2 (AGC ON)
- B/W: 0 Lux with IR ON
- Night Vision: Up to 100ft (30m) with IR LEDs
- Video Compression: H.264, H.265, H.264+, H.265+ (Baseline/Main/High Profile)
- Audio: Built-in microphone, adjustable volume (1-10)
- Recording:
- Supports MainStream or SubStream recording modes
- Pre-record and post-record options
- Recording schedule setup
- Image Control:
- IR-Cut Mode: Automatic, Color, B/W, or Schedule
- WDR (Wide Dynamic Range): Dynamic WDR for high contrast scenes
- 3D Noise Reduction: Auto/OFF
- Other Settings: Shutter speed, White balance, Backlight, AGC, Defog, and more
- AI Detection (when used with Camius NVRs):
- Human & Vehicle Detection, Perimeter Intrusion Detection (PID), Line Crossing Detection (LCD), Stationary Object Detection (SOD), Cross Counting, Sound Detection, etc
- Alerts:
- Motion Detection
- Sound Detection
- AI-based Detection (e.g., Human & Vehicle)
- Push Notifications to your smartphone
- Networking:
- Ethernet: RJ45 (10/100BASE-T)
- Protocols: DHCP, DNS, PPPoE, SNMP, Port Configuration (HTTP, HTTPS, RTSP, TCP, UPNP, P2P), etc.
- Email Alerts: Up to 3 receivers with encryption (SSL/TLS)
- Power:
- Power Supply: Power-over-Ethernet (PoE) IEEE802.3af, or DC 12V
- Power Consumption: 4W/5.5W (with IR on), 2W/3W (without IR)
- Environmental:
- Ingress Protection: IP66-rated, dustproof and waterproof
- Operating Temperature: -22°F to 131°F (-30°C to 55°C)
- Humidity: Less than 95% RH (non-condensing)
- Physical:
- Dimensions: Approx. 3.94” x 3.54” (100 x 90 mm)
- Weight: Approx. 15oz (420g)
Included in the Box:
IRIS8R Camera with a Mounting Kit, Waterproof Lid, Mounting Template, Quick Setup Guide
FAQ
Can Ethernet power a security camera?
Yes, Ethernet can power a security camera if the camera supports Power over Ethernet (PoE). Camius PoE cameras utilize this technology, allowing both data and power to be transmitted through a single Ethernet cable. This simplifies installation, reduces cable clutter, and ensures a more reliable and efficient setup.
Can you use Ethernet cable for security cameras?
Yes, Ethernet cables are perfect for security cameras, particularly those from Camius that support PoE. Camius PoE cameras benefit from the reliable data transmission and power delivery provided by Ethernet cables, ensuring consistent performance and easier installation.
How do Ethernet security cameras work?
Camius Ethernet security cameras connect to your network via Ethernet cables, combining data and power into a single connection if PoE is supported. These cameras offer robust video data transmission to network video recorders (NVRs) or cloud storage, providing reliable remote access, seamless monitoring, and excellent image quality.
Are power over Ethernet cameras good?
Yes, Power over Ethernet (PoE) cameras, especially those from Camius, are highly effective. They offer easy installation with a single cable for both power and data, reducing cable clutter and providing a secure, reliable connection. Camius PoE cameras also deliver high-quality video, making them an excellent choice for both home and business security systems.
How to configure Camius NVR using a web browser?
Using the Camius Device Config Tool (search tool), find your NVR on your local network and click on the IP address of the NVR, which will take you to the web browser.
How to activate Motion Detection
To make sure motion detection is activated, please check the following settings:
On the NVR interface, move the mouse cursor to the bottom left, click the main menu button, and then click Setup >> Channel >> Motion >> tick the Switch checkbox.
If you are adding R-series Camius IP cameras, you can also select target detection.
For the full guide, click here
What does NVR mean in security cameras?
NVR stands for Network Video Recorder. It is a device that records video from IP cameras over a network. Camius NVRs offer high-quality video and audio storage, remote access, and seamless integration with Camius IP cameras, providing a robust and efficient security solution.
Are NVR cameras better than DVR?
Yes, NVR cameras are generally better than DVR systems, especially for modern security needs. Camius NVRs support higher resolution IP cameras, offer easier installation with PoE, and provide advanced features like remote viewing and smart detection, making them a superior choice over traditional DVR setups.
Can I use any NVR with my security cameras?
Not all NVRs are compatible with every security camera. However, Camius NVRs are designed for seamless integration with Camius IP cameras, ensuring optimal performance, enhanced features, and reliable video storage. Using Camius NVRs with Camius cameras guarantees the best results.
What are the 2 types of NVR?
The two types of NVRs are PoE NVRs and wireless NVRs. Camius offers both, giving users the flexibility to choose the best option for their needs. Camius PoE NVRs provide power and data through a single Ethernet cable, simplifying installation and ensuring stable connections. Camius wireless NVR systems are ideal for low-traffic locations where wiring is difficult or impractical, offering flexible placement and easy installation. For a complete wireless solution, check out Camius 4K battery-operated cameras with a wireless NVR.
