Analog CVBS, AHD, CVI and TVI Camera Connection Explained

Difference between CVBS, AHD, CVI and TVI camera connections

AHD Camera

AHD stands for “Analog High Definition” and means an analog closed-circuit television video surveillance standard that uses a coax cable to transmit HD 720P and 1080P video from a security camera to a security camera recorder DVR (Digital Video Recorder).

HD TVI Camera

HD TVI cameras, also known as High Definition Transport Video Interface cameras, provide high-quality, high-definition video surveillance solutions up to 4K.

HD CVI camera​

HD CVI (High Definition Composite Video Interface) is an analog transmission standard-based over-coaxial cable delivering two HD video formats: 1920H or called otherwise, Full HD 1080P (1920×1080) & 1280H or called otherwise 720P (1280×720) through progressive scanning.

CVBS camera

CVBS stands for “Composite Video Blanking and Sync” (you can find a more detailed theoretical explanation on Wikipedia). It is a conventional analog signal delivered through an analog BNC connector. It can also be delivered through an RCA connector or other types (older cameras sometimes used a PL-259 connector). The CVBS  signal can support a maximum 960H video resolution. 960H represents the number of horizontal pixels in a video signal transmitted by a camera or a security camera digital video recorder (DVR). 960H represents 960 x 576 (PAL) or 960 x 480 (NTSC) pixels; you can compare it with the lower D1 resolution, which provides 720 x 576 pixels (PAL), or 720 x 480 pixels (NTSC).

Upgrading your DVR Camera System to Camius

Why upgrade your low-resolution and outdated analog camera system with Camius 4K Hybrid Security DVR?

  • Compatible with existing coaxial cables, power sources, and various types of analog cameras (CVI, TVI, AHD, CVBS) and IP cameras.
  • Experience advanced technology with features like smart motion detection, intelligent sound detection, PIR, and AI detection.
  • Enhance security with Camius spotlight security cameras that can activate lights and sirens as deterrents.
  • Save footage for extended periods with advanced audio and video compression.
  • Access and control your security system remotely with the Camius View smartphone app, PC, Mac compatible software, and web browser view.
  • Conveniently review recorded footage on the go by scanning the DVR’s QR code.
  • Trust in the quality, durability, and warranty of Camius surveillance video recorders and cameras.
  • Benefit from reliable US-based support for your home or business security needs.

Analog security cameras CVBS, AHD, CVI and TVI camera video format types are part of the latest HD CCTV standard, allowing high-definition digital video transmission over existing coaxial cables. With Camius DVR recorders, you can use regular CVBS BNC cameras as well as connect AHD, HD TVI, and HD CVI cameras without the need to change the coaxial cable infrastructure.

Remote Monitoring of your Security Cameras

Monitor your system remotely from anywhere globally using a built-in P2P (peer-to-peer) service or static IP / DDNS with port forwarding. View and control your Camius system with video management software designed for PC and Mac users. Camius DVR recorders work with multiple web browsers including Firefox, Safari, Opera, Chrome, Edge.
